| Parameter | Describe |
|---|---|
| Main chip | HT7315 |
Target Applications | 4K Monitor, Educational Whiteboard, Meeting whiteboard; |
| Panel Type | V-by-one or EDP (4/8LaneHBR2) |
| Panel resolution | 3840*2160 |
| Power input | Single 12V, single 24V or multiple power supplies, recommended 24V for PD3.0 fast charging |
| Screen TCON power supply | 3.3V - 12V |
| Picture in Picture | Support POP,PIP |
| Local Dimming | Mini-LED Local Dimming |
| Automatic Port | Automatic Port Signal Recognition,Seamless Switching |
| Audio amplifier | 2x8Ω10W |
