| Parameter | Describe |
|---|---|
| Main chip | TSUMV53RUU-Z1 |
| Target Applications | Commercial display, monitor |
| Panel Type | LVDS |
| Panel resolution | 1920x1200 |
| Power input | 12V |
| Screen TCON power supply | 3.3V, 5V/12V (Jumper selection) |
| Scalable functionality | Touch frame interface, serial port control protocol, RTC clock, automatic playback of mixed images and videos |
| Audio amplifier | 2x8Ω10W |
