产品特点

是一款2K-4K信号转接板（1920*1080@60Hz→ 3840*2160Hz@60Hz 转换），提供标准Full-HD LVDS输入接口(LG定义)，经过Scaler图像放大及MEMC等图像处理，生成4K超高清V-by-One型号，并直接驱动4K@60Hz面板，输出支持0(单)分区、2分区4K V-by-One信号格式。PS-6M38-A 也可以支持到LVDS 4 port输(3840*2160@30Hz)。支持2K-120Hz Vbyone接口120Hz OLED屏。

PS-6M38-A doubles the pixels (1920*1080@60Hz → 3840*2160Hz@60Hz conversion) of the video signal output (Full-HD signal by LVDS interface) from a TV control board and then supplies the 4K*2K@ 60Hz video signal to a panel provided with V-By-ONE input. It supports 0/1/2 Division V-By-One data format out.PS-6M38-A also supports 4 port LVDS UHD input (3840*2160@30Hz),and convert to 3840*2160Hz@60Hz to drive various 8 lane V-By-One UHD panel. It also can drive 2K-120Hz 4 Lane V-by-one interface OLED panel.
